Aventa 90mm Timber Profile
| Certified since | 03 Luglio 2026 |
| Climate zone | Molto caldo |
| Tipo | Operable |
| Sub type | |
| Efficiency class | phC |
| Material | Timber |
| UW | 1,00 W/(m2K) |
| Open type |
Descrizione
Wood frame (spruce/fir, 0,110 W/(mK)). Glazing thickness 44mm (4/12/4/18/6), rebate depth 16mm, spacer: SWISSPACER Ultimate with butyl secondary seal.
| Nome | Frame width | U-value | Ψ-value | Frsi-value |
|---|---|---|---|---|
| Flying Mullion | 130 mm | 1,00 W/(m²K) | 0,024 W/(mK) | 0,63 |
| Bottom | 130 mm | 1,11 W/(m²K) | 0,024 W/(mK) | 0,71 |
| Head | 115 mm | 1,00 W/(m²K) | 0,024 W/(mK) | 0,72 |
| Jamb | 115 mm | 1,00 W/(m²K) | 0,024 W/(mK) | 0,72 |
