2617wi07 Aventa 90mm Timber Profile: (可打开)
2617wi07 Aventa 90mm Timber Profile: (可打开): OB1
2617wi07 Aventa 90mm Timber Profile: (可打开): FM1
2617wi07 Aventa 90mm Timber Profile: (可打开): OH1
2617wi07 Aventa 90mm Timber Profile: (可打开): OJ1
Aventa 90mm Timber Profile
| Certified since | 2026年7月3日 |
| 气候区 | 相当炎热 |
| 种类 | 可打开 |
| Sub type | |
| 能效阶级 | phC |
| 材料 | 木材 |
| UW | 1.00 W/(m2K) |
| 打开种类 |
描述
Wood frame (spruce/fir, 0,110 W/(mK)). Glazing thickness 44mm (4/12/4/18/6), rebate depth 16mm, spacer: SWISSPACER Ultimate with butyl secondary seal.
| 名子 | 边宽高度 | U-value | Ψ-value | Frsi-value |
|---|---|---|---|---|
| 立柱 | 130 mm | 1.00 W/(m²K) | 0.024 W/(mK) | 0.63 |
| 下横框 | 130 mm | 1.11 W/(m²K) | 0.024 W/(mK) | 0.71 |
| 上横框 | 115 mm | 1.00 W/(m²K) | 0.024 W/(mK) | 0.72 |
| 侧面 | 115 mm | 1.00 W/(m²K) | 0.024 W/(mK) | 0.72 |
